Two versions of the Oasys Ground Movement bundle are available, each designed for a particular type of project situation.
The Pro level bundle aimed at large infrastructure projects includes XDisp Pro which provides for the calculation of movement and damage assessment at multiple points along a chosen path with PDisp and Slope.
Oasys PDisp predicts the likely movement of the ground due to imposed loads and consolidation. Results from PDisp can be exported to XDisp for a prediction of consequent building and utility damage.
Results from PDisp can be imported into XDisp for inclusion in utility and building damage assessment.
Oasys Slope calculates the stability factors of safety for built and excavated slopes.
The component tools that make up the geotechnical bundles can be installed and used separately and concurrently if required.
For technical details please refer to the individual application pages.
